Want a 3.5" lift that rides smooth, tows confidently, and stays planted under power?

The PMF 3.5" Alpha Lift Kit delivers a comfortable street ride and added travel up front, plus a rear setup designed to keep factory payload while controlling axle wrap when you’re towing or putting power down.

• Fits: 2017, 2018, 2019, 2020, 2021, 2022 Ford Super Duty F-250, F-350, F-450
• Intended use: Comfortable daily driving, confident towing, and a stable rear end for higher-HP builds

Why Choose the PMF Alpha 3.5" Lift Kit?

• Smoother ride + more control: Progressive dual-rate coils improve street comfort and provide additional travel vs. stock for better control on rough roads and job sites.
• Towing stability: Rear system retains the OEM leaf pack to maintain payload, then adds a gusseted traction bar kit to reduce wheel hop and axle wrap.
• Dialed stance: Multiple rear block heights let you fine-tune level, slight rake, or a taller rear look.
• Built to last: Heavy-duty links, brackets, brake lines, and track bar components engineered for real-world use.

What’s Included

• Front Coils: 3.5" ICON progressive-rate springs
• Front Links: Short-Arm 4-Link with flex joints or Adjustable 3-Link
• Sway Bar: Heavy-duty replacement sway bar links
• Brakes: Full replacement stainless brake lines (front & rear; set up for dual rear lines)
• Steering/Centering: HD adjustable track bar
• Rear Traction: Stage 2 gusseted traction bar kit
• Rear Height: Fabricated blocks (choose height) + U-bolts with top plates
• Shocks: Multiple valved-for-this-kit options (see below)

Choose Your Front Setup

• Short-Arm 4-Link: Maximum control over axle movement and wheel hop—great for hard launches, sled pulls, and high-torque use.
• Adjustable 3-Link: Tighter steering feel, excellent street manners, more articulation and shock absorption off-road; fully adjustable caster.

Rear Blocks & U-Bolts

• Blocks: Choose your block height to fine-tune stance (level, slight rake, or higher rear).
• U-Bolts: Available in 5/8" or 3/4" diameters (select SRW or DRW to match your truck).

Leaf Pack Type (How to Pick)

• Standard Leaf Pack: Top leaf runs eye-to-eye; typical stack is ~2–3" thick.
• Top-Mounted Overload: Thicker stack with a small spacer between the main pack and the top overload (not fixed at the ends). Choose this if your pack is thicker than ~3".

Shock Options (Valved for This Application)

• Bilstein 5100: Great all-around ride and looks
• Bilstein 5160 (front resi): Step-up control; better seal orientation for harsh/salty climates
• Fox 2.0 IFP: Non-resi or front-resi packages for increased performance
• PMF-Tuned King 2.5 Resi: Ultimate on/off-road performance

Important Notes

• Front driveline: At ~3.5" lift, most trucks maintain acceptable front driveshaft angles for typical street/towing use. Aggressive off-road or high-angle use may warrant driveline upgrades—ask our team for guidance.

Who This Kit Is For

• Owners who want a true 3.5" lift with a comfortable daily ride
• Trucks that tow regularly and need rear stability
• Higher-horsepower builds that need to control wheel hop

Questions? We’re Here to Help.

Not sure which options to pick or how to configure your stance? Contact FASS Motorsports and we’ll get you dialed:

• Phone: 636-429-7020
• Email: [email protected]
