The PMF 2005-2010 Entry-Level 3″ System with Bilstein 5100 Rear provides a solid and affordable lift for your Super Duty truck—around 3″ up front, with rear shocks that match performance without going overboard!

Maintains factory load capacity while giving you improved stance, handling, and steering tie-ins.

Why Choose This System?

• Fabricated Lift Blocks – Designed to integrate with your U-bolts for solid rear lift without complicated mods.
• Bilstein 5100 Rear Shocks – Vehicle-specific rear shocks to improve control and damping off section roughness.
• Heavy-Duty Track Bar – 1.5″ OD .250″ DOM with oversized 1″ FK Heim joint provides better steering precision and durability compared to smaller joints.
• Radius Arm Drop Brackets Included – For proper front geometry and level stance.
• Sits Level with Stock Springs – No need to upgrade your front or rear springs to get a level stance.

What’s Included

• (2) Fabricated 3″ Top Mount Coil Spacers
• (2) Radius Arm Drop Brackets
• (2) Bilstein 5100 Shocks (rear shocks optional)
• PMF Adjustable Track Bar
• 4″ Lift Blocks for rear with 4 U-bolts
• Hardware kit included

Fitment & Specs

• Built for 2005-2010 Ford Super Duty trucks.
• Front lift achieved through coil spacers and drop brackets; rear lift via fabricated blocks.
• These “entry-level” upgrades improve ride quality slightly over stock while preserving factory load rating.
